Mini Film Blown Machine

Mini type film blowing machine can largely save energy, labor, workshop space, etc. The extruding ,cylinder, screws are made of quality alloy steel with optimum hardness and srtong corrosion resistance after nitrogen treatment and precision processing. The specially designed screw ensures output and good plasticization. It is suitable for blowing low density polyethylene (LDPE) and high density polyethylene (HDPE) and linear low density polyethylene (LLDPE) plastic film, which is widely used in the packing food, clothing, bags, vest bags and etc.

OPTIONAL EQUIPMENT:

1.AUTO LOADER
2.CORONA TREATER
3.DIE ROTARY DEVICE
4.DOSING DEVICE
5.HIGH SPEED NET CHANGER4

Product Description

Product Usage:

Mini type film blowing machine can largely save energy, labor, workshop space, etc. The extruding ,cylinder, screws are made of quality alloy steel with optimum hardness and srtong corrosion resistance after nitrogen treatment and precision processing. The specially designed screw ensures output and good plasticization. It is suitable for blowing low density polyethylene (LDPE) and high density polyethylene (HDPE) and linear low density polyethylene (LLDPE) plastic film, which is widely used in the packing food, clothing, bags, vest bags and etc.

OPTIONAL EQUIPMENT:

1.AUTO LOADER
2.CORONA TREATER
3.DIE ROTARY DEVICE
4.DOSING DEVICE
5.HIGH SPEED NET CHANGER4

MAIN TECHNICAL VARIABLES

ModelXYMN-600xyMN-800
Screw Diameter45mm55mm
Screw RatioL/D30:1L/D30:1
Screw Speed10-100r/min10-100r/min
Power of Main Motor11kw15kw
Max. Extrusion Output20-45kg/h30-55kg/h
Max. Folding Width of Film600mm800mm
Thickness of Film0.008-0.10mm0.008-0.10mm
Total Power28kw35kw
Weight of Machine2000kg2500kg
Overall Dimension(L×W×H)2.7×1.8×3.8m2.8×1.9×3.9m

Contact Our Experts

Trust your plastic packaging equipment to the industry's leading manufacturer

Our equipment utilizes high quality materials, advanced technology and strict quality control measures.
And we provide comprehensive support and assistance to our customers, not simply selling products, but also providing cutting-edge technology and services.

Get In Touch

Get customized solutions from professional bubble bag making machine manufacturers

Related Products

This machine is applied to produce HDPE, LDPE and LLDPE plastic film. It is widely used for packing food, garments, daily necessities,and other agriculture and industry use. It is equipped with three axis transmission hard surface gear reducer, traction frequency adjustment, independent torque motor rewinder, centrifugal blower, and air compressor (Rotary die head part can be chosen with extra charge).

OPTIONAL EQUIPMENT:

1.AUTO LOADER
2.COOLING MACHINE
3.CORONA TREATER
4.DIE ROTARY DEVICE
5.AIR COMPRESSOR
6.MANUAL NET EXCHANGER
7.HYDRAULIC FAST NET EXCHANGER

ABA blown film machine, has a unique advantage in the production of HDPE, LDPE and LLDPE material. The physical strength of the film is improved by co-extrusion. Its two hosts supply three-layer extrusion, one to blow internal and extemal coating layer, and the other supplies middle filling layer. It can decrease one of the hosts configuration for the purpose of reducing the cost,and saving energy. At the same time, the middle filling layer can add recycle material and calcium carbonate, which accounts for more than 80% of the total output. It can greatly reduce raw material cost in the process of production and provide customers with stronger market competitiveness.

OPTIONAL EQUIPMENT:

1.AUTO LOADER
2.CORONA TREATER
3.DIE ROTARY DEVICE
4.AIR COMPRESSOR
5.HIGH SPEED NET CHANGER

Three-to-Seven-layer co-extruding upper traction rotation blown film machine unit is designed and developed according to the market demands at the basis of domestic and foreign advanced technology. It is applied to packing with medium and high end film. The film is of well barrier property, retaining freshness, moisture-proof, frost prevention, oxygen proof and oil-proof. So it can be widely applied to the light-weight packing, such as fresh fruits,meat, pickles, fresh milk, drink, medicine, etc.

OPTIONAL EQUIPMENT:

1.AUTO AIR RING( ADJUST THE THICKNESS OF FILM AUTOMATICALLY)
2.IBC FILM BUBBLE INNER COOLING SYSTEM
3.AUTO THICKNESS MEASURE GAUGE
4.COMPUTER CONTROL SYSTEM

~
